Future-proof design
Up to 1200A output current
100kW power stacks
Voltage range of 150V to 1000V
Parallel DC charging of up to 3 cars
Public
Commercial
Hypercharger 400kW
DC
The Blink Hypercharger 400kW fast chargers are powerful enough to charge electric vehicles superfast. As many as three charging points can be set up in the Hypercharger’s configuration, for both AC and DC plugs – you can choose between CCS2, CHAdeMO, GB/T, Type 2 and even IEC charging connection options. A future-proof design allows scalable configurations and output from 150 to 1000 volts. Safety features protect the station with an external emergency stop switch, crash sensors and door sensors.. The Blink 400kW fast charger is seamlessly connected using the Blink Network and with 4G/3G/2G connections.
CHAdeMo
Type 2
CCS2
Models
| Product | 150kW | 400kW |
|---|---|---|
| Max Current Rating | 117 A, 80kW @ 75kW DC output power 233 A, 160kW @ 150kW DC output power | 600A |
| Max Charging Power | 75 kW (one Power-Stack), max. 250A 150 kW (two Power-Stacks), max. 500A | 100 kW (one Power-Stack), max. 300A 200 kW (two Power-Stacks), max. 600A 300 kW (three Power-Stacks), max. 600A 400 kW (four Power-Stacks), max. 600A |
| Voltage Rating | 3x 230 V (400 V) / 50 Hz | 380 V / 400 V / 480 V |
| Optional AC Sockets | 1 | 1 |
| Connectivity | 2G/3G/4G GSM-/CDMA modem, 10/100Base T Ethernet | LTE/UMTS/GSM Modem 4G/3G/2G 10/100Base-T Ethernet |
Product Documentation
Specifications Sheets
All the power you need from one unit
MULTI-PURPOSE
DC fast chargers that are multi-purpose and can charge up to three cars simultaneously, with a variety of available plugs and amperage options.
SUSTAINABLE
Durable design and high efficiency ensure vehicles can quickly and easily recharge while minimizing their environmental impact.
POWERFUL
The Blink 100kW to 400kW DC fast charging station is a powerful charging charger capable of stacking power output over multiple units.
Blink 100kW - 400kW DC Fast Charger
Fast and Efficient EV Charging
The Blink is a fast-charging solution with professional-grade features. It can charge three cars simultaneously with connection options like CCS2 and CHAdeMO. It performs well in all weather conditions and offers a powerful output of 500 Ampere, making it a top choice for eco-conscious consumers. With voltage ratings of 380 Q / 400 Q / 480 Q and dimensions of 732 x 2235 x 663 mm, it operates in MODE 4 with DC charging mode. It can deliver a maximum power of 400 kW, supporting a max current rating of 600 A. The Hypercharger 400kW is efficient and ready for 600 A with its floor mounting option.
“These new fast-charging options will enable more EV travel options. Now is a great time to make the switch."
David Roberts,
Drive Electric Vermont coordinator
Ready to design your EV Charging solution?
Learn how the Blink 100kW-400kW DC fast charger can attract new customers that stay longer and visit your business more frequently.
