Socket/cable variants available
Adjustable power: 7.4kW-22kW
Connects via Bluetooth, WiFi, Ethernet, 2G, 4G or LTE Cellular signal
ISO15118 certified
OCPP 1.6
V2G ready
MID Certified
Wall or Pedestal mounting options
EQ 200 – International AC-Type 2 Charger
The Blink EQ 200 is designed with flexibility in mind, to fit any location with its compact form and multiple installation options. This three-phase AC charging station produces a powerful 32 amps of output and offers a simplified management experience with networked remote support for configuration, maintenance, and hassle-free control of the charging station. With an innovative modular design, this charging station can be tailored to the specific needs of the market segment. This MID-certified charger is available in both a Type 2 socket or cable variants, and provides a scalable EV charging solution for international markets!
EQ 200 Versions | Essential | Residential | Professional |
---|---|---|---|
Power | 1x230V (50/60Hz) 3x400V+N (50/60Hz) | 1x230V (50/60Hz) 3x400V+N (50/60Hz) | 1x230V (50/60Hz) 3x400V+N (50/60Hz) |
Max Current | Up to 32A | Up to 32A | Up to 32A |
Max Charging Power | 7.4kW (single phase) 22kW (three-phase) | 7.4kW (single phase) 22kW (three-phase) | 7.4kW (single phase) 22kW (three-phase) |
Charging Socket | AC–Type 2 socket Optional: Schuko, Schutter Optional: Cable (7m) with AC-Type 2 plug | AC–Type 2 socket Optional: Schuko, Schutter Optional: Cable (7m) with AC-Type 2 plug | AC–Type 2 socket Optional: Schuko, Schutter Optional: Cable (7m) with AC-Type 2 plug |
Charging Mode | Mode 3 (IEC 61851) | Mode 3 (IEC 61851-1 ed. 3) ISO-15118 | Mode 3 (IEC 61851-1 ed. 3) ISO-15118 |
Connectivity | Bluetooth | Bluetooth, Wifi, Ethernet | Bluetooth, Wifi, Ethernet, 2G/4G/LTE |
Product Sheet
Product Manual
Specification Sheet
Reliable AC-Type 2 Charger
VERSATILE
Modular Design With Multiple Configurations
Flexible & Durable
Supports ISO-15118, OCPP 2.0, & Bi-Directional Charging
INTELLIGENT
Compatible With various Interface Protocols
Blink EQ 200
Intelligent, Scalable, & Flexible
The EQ 200 electric vehicle charger comes equipped with intelligent features and is able to interact with various Home Energy Management Systems (HEMS), with comprehensive access to remote controls. With the new two component setup, the installation time is cut down drastically.
An optional 7-meter cord with AC-Type 2 plug can be added to simplify the charging experience. The Blink EQ 200 charging station is a universal charger that can comply with all local regulatory requirements.
