Dual-port 22 kW design
8″ interactive touchscreen for enhanced user experience and digital marketing
Connectivity via 4G, Wi-Fi, and Ethernet
ISO 15118 hardware ready for Plug & Charge functionality
Rugged, weather-resistant design for public installations
Optional contactless Payter payment terminal
Commercial
AC Ultra Street Charging Station
AC
Level 2
The Autel AC Ultra Street charger is a sleek, dual 22 kW public EV charger designed for urban spaces, offering fast charging, digital advertising, and Plug & Charge readiness—providing convenience for businesses and local authorities.
Type 2
Product Details
| Specification | Details |
|---|---|
| Product | AC Ultra Street |
| Power Output | Up to 22kW per port (3-phase) |
| Ports | Two (Type 2 Sockets) |
| Input Voltage | 400 V ± 15%, 50 Hz |
| Connectivity | 4G, Wi-Fi, Ethernet, RS485 |
| Backend Protocol | OCPP 1.6J / 2.0.1 |
| User Authentication | RFID card, App, Credit Card (optional) |
| Display | 8-inch touchscreen (1280 × 720) |
| Payment Options | RFID, App, Payter (contactless) |
| Metering | MID-certified ± 1.0% accuracy |
| Operating Temperature | −30 °C to +50 °C |
| Protection Rating | IP54 / IK10 |
| Mounting | Floor-mounted |
| Dimensions (H x W x D) | 1450 × 310 × 200 mm |
| Weight | Approx. 45 kg |
| Certifications | CE, IEC/EN 61851-1 and related standards |
Product Documentation
Product Sheet
Specification Sheet
Why AC Ultra Street
Flexible
Multiple data connection options, including 4G, Wi-Fi, and Ethernet.
Intuitive
User-friendly interface for effortless charging sessions.
Durable
Weather-resistant construction built for long-term outdoor use.
AC Ultra Street Charging Station
Built for Busy Streets and Public Spaces
The AC Ultra Street Charger delivers advanced AC charging for public applications. Designed for high-traffic urban areas, it pairs modern aesthetics with robust performance. The 8-inch interactive touchscreen provides real-time charging data and doubles as a digital advertising display. With ISO 15118 readiness, flexible connectivity (4G, Wi-Fi, Ethernet), and a rugged IP54/IK10 enclosure, it’s engineered for reliability, uptime, and easy integration into any city environment.
Ready to Deploy AC Ultra Street?
Talk with Blink about installation, site design, and bulk orders.
